                    VOA Radiogram

La Radio in Bottiglia

28 giugno 2014 17860 KHz 16:00 16:30 GMT

SINPO 55555

29 giugno 2014 15670 KHz 19:30-20:00 GMT

SINPO 54554

Il testo trasmesso con l'immagine:

VOA Radiogram has many listeners in Italy, and many of these

Italian listeners are members of A.I.R., Associazione Italiana

Radioascolto.

The A.I.R. held its 32nd annual meeting on 9-10 May in Turin

(Torino). One of the activities at the meeting was the launch, in

the River Po, of a bottle containing a 10-milliwatt beacon

transmitting on 28325 kHz...

RX: ICOM 756 pro

ANT: Verticale HF 10-40 Mt  (10Mt)

Intref.: SB2000

PC: laptop Pentiunm II

Soft: FLDigi V.3.21.83

'73 de IK1XPK, Claudio.

SAQ 17,2 KHz 29 giugno 2014

Alcune videate del segnale della stazione Radio SAQ a 17,2 KHz effettuate con Spectram dalle 08:40 alle 09:00 UTC.

Il file audio registrato alle ore 08:40 UTC

IK1XPK, Claudio.

EA0JC - King of Spain Juan Carlos de Borbón

Ieri Juan Carlos Re di Spagna si è affacciato, dopo tempo che succedeva, sulle frequenza Radioatoriali con il suo Call EA0JC.
Re Carlos ha operato in CW e SSB su varie bande; personalmente ho ascoltato sui 40 Mt CW con segnale molto basso e collegato in 10 Mt e 21 Mt SSB ieri 28 giugno e oggi in 20 Mt SSB sempre durante il Contest spagnolo.

King of Spain Juan Carlos de Borbón, EA0JC
Royal Palace
Madrid
Spain

QSL only Bureau.

QSO EA0JC Carlos <->  I1HJP Paolo

28 MHz SSB 28/giugno/2024 19:40 GMT

CQ de EA0JC on 21 MHz

'73 de IK1XPK, Claudio

VOA Radiogram, 17860 KHz - 28 June 2014, Reception

Alcune immagini dell'ascolto della VOA Radiogram di oggi 28 giugno sulla frequenza di 17860 KHz AM - MFSK32 dalle 16:00 alle 16:30 UTC.

ricevitore un ICOM 756 pro,
antenna una vertivale HF da 40 a 10 mt alta circa 10 mt,
interfaccia USB SB-2000
PC Pentium II
Soft. FLDigi V 3.21.83.
SINPO 55555

'73 Claudio IK1XPK

W1AW Code Practice MP3 Files

Impariamo il CW con l'ARRL. Sul sito Web della più grande Associazione mondiale di Radioamatori troviamo alcune parte dedicare all'apprendimento del codice morse (CW) utile anche a chi si diletta di solo ascolto.

Tralasciando la possibilità di partecipare a contest che precedano questo tipo di emissione il quali possono essere difficoltosi per un novice apprendere il CW è senza dubbio utile per l'ascolto delle stazioni utility che operano in telegrafia o per identificare i beacon.

Avevo già parlato della stazione militare francese FAV22 che organizza corsi di telegrafia in collaborazione con la REF in un precedente post http://laradioa360gradi.blogspot.it/2014/03/fav22-impariamo-il-morse.html ora vediamo il servizio on-line offerto dalla ARRL.

La pagina di riferimento è la seguente http://www.arrl.org/code-practice-files; nella pagina viene presentato il programma e si ha la possibilità di scaricare file MP3, magari per riascoltarsi con un telefonino di ultima generazione nei momenti di pausa, con relatico testo per confrontare la propria abilità nel ricevere con quanto ascoltato. I testi non sono i solito gruppi di cinque lettere o numeri ma veri e propri testi.

e' possibile approcciarsi all'ascolto con velocità diverse che variano da 5 WPM a 40 WPM. sul sito ritroviamo anche l'archivio dei file MP3 dal 2013.

W1AW Code Practice MP3 Files

Listed here are W1AW code practice transmissions for the dates and speeds indicated. The files are in MP3 format, playable using Windows Media Player, RealPlayer or your favorite MP3 player.
The files are updated every other week.
The first link is used for streaming audio -- click on the link to have the player play the code practice as it receives it. It may also be used to download the code-practice file to disk for later playback. (In Windows, right-click on the link to the file you want to save to get a menu of options.) Not all MP3 players will treat the link the same, and some players may not work on the link type.
The second link is the actual text of the code practice file.  Please note that the text file may contain control characters.  You will hear these characters as regular Morse code prosigns or abbreviations.

Files

Text Source for W1AW Web Code Practice Files for June 24 and 25, 2014:
Text for the 5 to 15 WPM runs comes from November 2013 QST, page 85.

Text for the 20 to 40 WPM runs comes from December 2013 QST, page 90.

The various archive files are available from the following links.  Access to each other archive is also available from any of these various pages:

5 WPM files	20 WPM files
7.5 WPM files	25 WPM files
10 WPM Files	30 WPM files
13 WPM Files	35 WPM files
15 WPM Files	40 WPM files
18 WPM files

The 18 WPM is a "transition" file to help bridge the gap from 15 to
20 WPM.  The file contains word and letter groups sent at 18 WPM
with an 18 WPM character speed.

This particular file is actually part of the W1AW CW bulletin from
previous weeks.  This allows for a different transition file with
each update.

The 40 WPM file is composed of texts taken from the lower speed
files.

The various TEXT files contain the actual code practice text used in
each run.  Please note the embedded "control characters" (used to
generate the CW prosigns) are included in the text.

Please note the tone frequency is 750 Hz.

Questions or comments about these files may be directed to:

Joe Carcia, NJ1Q   -  nj1q@arrl.org

http://www.arrl.org/code-practice-files
http://www.arrl.org/5-wpm-code-archive


'73 de IK1XPK, Claudio

VOA Radiogram, 28-29 June 2014, CQ FD

Ancora l'A.I.R. protagonista nelle trasmissioni digitali della VOA Radiogram; la "Radio in bottiglia" torna alla ribalta in un trasmissione digitale della VOA.

Al 23° minuto l'AIR.

23:08  Associazione Italiana Radioascolto 10M river beacon, with image.

Grazie a  Kim Elliot.

La mail di Kim.

Hello friends,

Some of our North American listeners may be busy this weekend because of the annual amateur radio Field Day event. If you are participating, you might want to take a break to tune in VOA Radiogram and demonstrate the concept to other radio amateurs. This weekend's program will include items that will be of interest to anyone involved in radio.

Here is the lineup for VOA Radiogram, program 65, 28-29 June 2014 (MFSK32):

  1:36  Program preview
 2:40  Field Day greetings to radio amateurs, with image
 5 03  VOA Cold War broadcasts from a Coast Guard cutter, with image
14:25  Scientists push for continued HAARP funding, with image
23:08  Associazione Italiana Radioascolto 10M river beacon, with image
26:30  Closing announcements

There will also be two surprise modes at the end of the show.

Please send reception reports to radiogram@voanews.com.

Again this weekend, VOA Radiogram is recorded at a sample rate of 8000 Hz. This does not seem to have any negative effect on the decoding of the digital modes, but it does make the opening and closing music sound muddy and low-fi. Now that I've remembered the Fldigi Configure > Sound Card > Wav setting, things should be back to normal next week.

VOA Radiogram transmission schedule
(all days and times UTC):
Sat 0930-1000 5745 kHz
Sat 1600-1630 17860 kHz
Sun 0230-0300 5745 kHz
Sun 1930-2000 15670 kHz
All via the Edward R. Murrow transmitting station in North Carolina.

Kim

Kim Andrew Elliott
Producer and Presenter
VOA Radiogram

voaradiogram.net

This weekend, The Mighty KBC will also transmit greetings to Field Day participants this weekend. A minute of MFSK64 will be transmitted Saturday at about 1130 UTC on 6095 kHz, and Sunday at about 0130 UTC (Saturday 9:30 pm EDT) on 9925 kHz. Both frequencies are via Germany. Reports to themightykbc@gmail.com .

 I hope you can tune in and email in this weekend.

Kim

Kim Andrew Elliott
Producer and Presenter
VOA Radiogram
voaradiogram.net


'73 de IK1XPK, Claudio

SAQ Extra trasmission and SK6SAQ

Extra transmission on Wednesday 2 July 2014

An extra transmission will be performed on Wednesday 2 July at 14:30 UTC to celebrate the 10th anniversary of the World Heritage appointment of SAQ. We start the transmitter at 14:00 UTC and a test signal will be transmitted from about 14:10 UTC. The frequency is 17.2 kHz CW.

We do not require any QSL-reports on this SAQ transmission and will not verify.

SK6SAQ

Amateur Radio Station with special event call SK6SAQ will be QRV on the Alexanderson Day 29 June 2014, 08:00 – 14:00 UTC (excepting when SAQ is on air) on any of the following frequencies:

- 14 035 kHz CW

- 14 215 kHz SSB

-  3 535 kHz CW.

QSL for SK6SAQ via SK6DK or bureau.

During the summer SK6SAQ will be QRV on Tuesdays 16.30-19.00 UTC and Thursdays 09.00-11.00 UTC.

http://alexander.n.se/in-english/saq-transmission/

The receiver in Twente

In Twente in The Netherlands is a receiver that continuously streams the reception of longwave, mediumwave and shortwave on the Internet. The receiver can be accessed by clicking here. Then type in the frequnecy field 17.2 kHz, in the Waterfall view field click max in, in the bandwidth field click on CW-narrow. If necessary, adjust the frequency to 17.2 kHz. Good luck!

Video

'73 del IK1XPK Claudio

Morse and Music

Vadrum Speaks Morse Code (Drum Video)

Video da youtube

Codice Morse

'73 IK1XPK Claudio

SAQ Transmission on 17,2 KHz

Official transmissions

Grimeton Radio Station was listed as a world heritage site because its original equipment is an exceptionally well-preserved example of the development of communication technology. In fact, it is still in working order. Grimeton (call sign SAQ) still transmits a message to the world twice a year: at the Alexanderson Day (Sunday at the end of June/beginning of July) and at Christmas Eve. Next transmission is planned to take place on the Alexanderson Day Sunday 29 June 2014.
Groups can also book an exclusive start-up demonstration as part of their visit to the world heritage site. Contact the World Heritage Grimeton for more information.

Transmissions on Alexanderson Day Sunday 29 June 2014

SAQ will be on air on Sunday 29 June. We try to start the transmitter soon after 08.30 UTC so there will be a test signal from about 08.40 UTC and a message will be sent at 09.00 UTC. A similar procedure will start at 11.30 UTC and the message will be repeated at 12.00 UTC. The frequency is 17.2 kHz CW.

Listeners reports

QSL reports can be given via:
- E-mail to: info@alexander.n.se
- or via SM bureau
- or direct by mail to: Alexander – Grimeton Veteranradios Vaenner, Radiostationen, Grimeton 72, SE-432 98 Grimeton, SWEDEN

Note: SAQ is a member of the Swedish Amateur Association (SSA) and ”QSL via bureau” is OK.

http://www.alexander.n.se/startsida.htm


'73 Claudio IK1XPK

QSL speciale 32° Atlantic 2000

E-QSL speciale per il 32° anniversario della radio.

Come promesso l'emittente ha inviato a coloro che hanno ascoltato la trasmissione di domenica 8 giugno e inviato regolare rapporto d'ascolto la E-QSL commemorativa per i 32 anni di attività.

Personalmente ho ascoltato l'emittente Francese su 9485KHz con un SINPO 34343; l'antenna la solita verticale per le HF (40-10 Mt) il ricevitore l'ICOM 756 PRO.

La richiesta di E-QSL è stata effettuata via mail con allegati alcuni minuti di registrazione effettuata con il PC al seguente indirizzo mail: atlantic2000international@gmail.com

Oltre E-QSL la  l'emittente radio ha inviato un "Atlantic2000_Bulletin" in formato pdf.

Il bollettino

Testo del bollettino in francese.

ATLANTIC 2000

Ondes courtes et Internet

Après avoir émis en FM de 1978 à 1982, Atlantic 2000 International a été entendue pour la

première fois en ondes courtes le 6 juin 1982, sur 7325 kHz.

Les émissions suivantes ont été diffusées mensuellement jusqu’en juillet 1988.

Le premier émetteur ondes courtes, de confection locale, avait une puissance de 25 W.

Un second équipement, d’une puissance de 30 W, également de confection locale, fut mis en

service en 1984.

Nous avons testé les bandes des 48, 41, 38 et 26 mètres, et c’est la bande des 41 m qui a donné les

meilleurs résultats d’écoute en Europe.

Après plus de 19 ans d’absence, Atlantic 2000 est revenue sur les ondes le 28 octobre 2007,

sur 6280 et 6210 kHz.

De 2008 à 2010, Atlantic 2000 a diffusé ses émissions depuis l'Italie, sur les émetteurs de

Mystery Radio, puis de Radio Amica. Au mois de décembre 2010, nos programmes ont commencé

à être diffusés sur 6005 kHz, depuis le site de Kall-Krekel en Allemagne, exploité par Radio 700.

Depuis ce même site, nous pouvons émettre également sur 7310 kHz.

Depuis le 16 octobre 2011, Atlantic 2000 émet régulièrement dans la bande des 31 mètres, via MV

Baltic Radio, située à Göhren en Allemagne. La fréquence actuelle est de 9485 kHz.

Nous avons reçu une grande quantité de rapports d'écoute provenant d'Allemagne, Autriche,

Belgique, Bulgarie, Danemark, Espagne, Finlande, France, Grande-Bretagne, Grèce, Hongrie, Inde,

Italie, Japon, Kazakhstan, Lettonie, Luxembourg, Norvège, Nouvelle Zélande, Pays-Bas, Pologne,

Portugal, République Tchèque, Roumanie, Russie, Serbie, Slovaquie, Suède, Suisse, Ukraine et

USA.

Atlantic 2000 est audible dans le monde entier sur Internet.

Vous êtes très nombreux à vous connecter et à apprécier ce nouveau mode de transmission.

A bientôt sur Atlantic 2000.

http://radioatlantic2000.free.fr

Good DX, IK1XPK Claudio.

The Hobbyists Guide to RTL-SDR

Dal sito RTL-SDR.com apprendiamo della pubblicazione di un Ebook per Kindle, intitolato "The Hobbyists Guide to RTL-SDR." Il libro comprende molti suggerimenti e tutorial pubblicati ne tempo sul sito RTL-SDR Il contenuto è principalmente destinato a chi si avvicina per la prima volta al mondo  RTL-SDR.

http://www.rtl-sdr.com/new-ebook-hobbyists-guide-rtl-sdr/

Chi non avesse un dispositivo Kindle per leggere libri per Kindle! Ci sono lettori disponibile per varie piattaforme Windows, Mac, browser Web, Android e iOS.

L’indirizzo di Amazon dove acquistare il libro:

http://www.amazon.com/gp/product/B00KCDF1QI/ref=as_li_tl?ie=UTF8&camp=1789&creative=390957&creativeASIN=B00KCDF1QI&linkCode=as2&tag=txtl02-20&linkId=3VTJX2QK7BZVATRE

Atlantic 2000 - Sunday 8th of June - 32nd anniversar​y show

Atlantic 2000 will be on the air this Sunday 8th of June from 08:00 to 09:00 UTC (10:00 to
11:00 CEST) on 6005 and 9485 kHz.
The programme will be streaming at the same time on our website.
For this 32nd anniversary show, all correct and detailed reception reports will be confirmed by a special QSL-card.

Atlantic 2000 émettra sur 6005 et 9485 kHz ce dimanche 8 juin de 08:00 à 09:00 TUC (10:00 à 11:00 heure de Paris).
L'émission sera diffusée à la même heure sur notre site internet.
A l'occasion de notre 32ème anniversaire, les rapports d'écoute complets et détaillés seront
confirmés par une carte QSL spéciale.

http://radioatlantic2000.free.fr

Atlantic 2000 sarà in onda questa Domenica 8 Giugno 8:00-09:00 UTC (10:00 a
11:00 CEST) su 6005 e 9485 kHz.
Il programma sarà in streaming allo stesso tempo sul nostro sito.
Per questo anniversario spettacolo 32nd, tutte le relazioni corrette e dettagliate di accoglienza saranno confermati da una speciale QSL.

Atlantic 2000 problema su 6005 e 9485 kHz questa Domenica 8 Giugno 8:00-09:00 UTC (10:00-11:00 ora di Parigi).
Lo show andrà in onda nello stesso momento sul nostro sito.
In occasione del nostro 32 ° anniversario, le relazioni di ascolto e dettagliati completo sarà
confermato da QSL speciale.

http://radioatlantic2000.free.fr

Old QSL Atlantic 2000

Claudio IK1XPK

IQ2MI e Spectran V.2

Dopo l’ascolto classico ad "orecchio" del Beacon IQ2MI a 474 KHz di alcune sere fa

http://laradioa360gradi.blogspot.it/2014/05/beacon-iq2mi-474-khz.html

o

http://air-radiorama.blogspot.it/2014/05/beacon-iq2mi-474-khz.html

ecco un esempio di ascolto effettuato con un software tutti italiano realizzato da

Alberto I2PHD e  Vittorio IK2CZL  - SPECTRAN V.2.

Il programma di facile utilizzo ma comunque corredato di manuale scaricabile on-line è reperibile con altri ottimi software utilizzando il seguente link:

http://digilander.libero.it/i2phd/spectran.html

oppure direttamente sul sito:

http://www.weaksignals.com/

Ecco l’immagine ricevuta questa sera in u momento di calma atmosferica con rumore minimo. Il QSB era abbastanza profondo tipico dei queste frequenze; il ricevitore un ICOM 756 PRO l’antenna una verticale HF multi banda di circa 10 Mt, il PC un AMD 4core 3.0 Ghz. Il segnale è stato prelevato dal ricevitore utilizzando la  presa cuffia e iniettato nel PC nella presa micro separando le due apparecchiature con trasformatore di isolamento da 600 ohm.

'73 Claudio IK1XPK

IRDR Trial - Jakarta

Mail from:

Kim Andrew Elliott

Producer and Presenter

VOA Radiogram

Hello friends,

A coordinated shortwave broadcasting event will take place during the trial of International Radio for Disaster Relief (IRDR), during the Media Summit on Climate Change, ICTs and Disaster Risk Reduction, 5-6 June 2014, in Jakarta, Indonesia.

More information, including the transmission schedule, is here...

http://hfcc.org/humanitarian/irdrtrial.phtml

Reception might be difficult in North America. Try this web-SDR receiver in the Netherlands: htp://websdr.ewi.utwente.nl:8901/

The U.S. International Broadcasting Bureau slots are 0800-0830 and 0900-0930 UTC both days. I prepared a special VOA Radiogram for this event, but VOA/IBB decided, for whatever reason, to use a BBC program instead.

The special VOA Radiogram will be transmitted this weekend, 7-8 June, during its usual four half hours...

(all days and times UTC)

Sat 0930-1000 5745 kHz

Sat 1600-1630 17860 kHz

Sun 0230-0300 5745 kHz

Sun 1930-2000 15670 kHz

All via the Edward R. Murrow transmitting station in North Carolina.

During this weekend, please send reception reports to HFCC, the shortwave frequency coordination association and organizer of  International Radio for Disaster Relief, at info@hfcc.org -- as well as to the usual VOA Radiogram address: radiogram@voanews.com .

You might mention to HFCC how text via shortwave can be useful during and after emergencies and, unlike DRM, reception does not require a special shortwave receiver.

I will send another e-mail later this week with results of our EasyPal experiment and more information about the next VOA Radiogram, program 62, 7-8 June 2014.

Kim

Kim Andrew Elliott

Producer and Presenter

VOA Radiogram

voaradiogram.net

More info:

http://hfcc.org/doc/HFCC_RAD_2014-004-IRDR_Jakarta_Presentation.pdf

UTC	Organisation	Notes
0200-0230	21840 kHz ABC Radio Australia Antenna HRS 4/4/0.5, 329deg 100 kW Shepparton
0230-0530	15650 kHz BBC/Babcock/DRM Nakhon Sawan, Thailand LPH 150 deg.
0500-0530	21840 kHz Radio Vatican
0530-0600	15650 kHz SLBC Sri Lanka Trinkomalee
0600-0700	15650 kHz First Response Radio/FEBC Philippines
0700-0730
0730-0800	21840 kHz MGLOB Madagascar 250 kW bearing 085 deg. antenna TM	Alternative: 0930-1000
0800-0830	15650 kHz IBB Site: UDO
0830-0900	15650 kHz NHK WORLD RADIO JAPAN Palau - 270 deg.
0900-0930	15650 kHz IBB Site: PHT
0930-1000
1000-1030	15650 kHz All India Radio Bangalore 500 kW 4/4/0.5 at 120 deg
1030-1100	21840 kHz RTC - China Standard Chinese site: BEI
1100-1130	15650 kHz KTWR Guam

'73 IK1XPK Claudio
